Use our IP cheatsheets to integrate APIs from popular smart home brands directly in to uOS for use with the uControl App and Remote.
Can’t see a brand that you work with? Contact us to find out if we can integrate it into uOS.
Before starting we recommend you have the following tools on your computer
a) Terminal emulation program. We recommend Hercules SETUP utility – Produced by www.HW-group.com.
b) An API test tool such as Postman – Download Postman
| Name | uOS Connection | Command Generator |
|---|---|---|
| Audioflow | Connection Type: PUT PORT: 80 AUTH/HEADER: NONE |
N/A |
| Gude | Connection Type: GET PORT: 80 AUTH/HEADER: NONE |
Gude Command Generator |
| KNX | Connection Type: GET PORT: 80 AUTH/HEADER: NONE |
KNX Command Generator |
| Loxone | Connection Type: GET PORT: 80 Authentication = HEADER Header data = {“Authorization”:”[code]"} [code] = user:pass converted to Base64 (user and pass configured inside Loxone Users) |
N/A |
| Lutron Ra2 | Connection Type: TELNET PORT: 23 Authentication = LOGIN Header data = {"lutron":"integration"} |
N/A |
| Netio | Connection Type: GET PORT: 80 AUTH/HEADER: NONE |
N/A |
| P5 | P5 Examples | N/A |
| Philips Hue | Connection Type: PUT PORT: 80 Authentication = HEADER Header data = {"hue-application-key":"[key]"} |
Hue Command Generator |
| Rako | Connection Type: TCP PORT: 9762 AUTH/HEADER: NONE |
Rako Command Generator |
| Shelly | Connection Type: GET PORT: 80 AUTH/HEADER: NONE |
Shelly Command Generator |
| Silent Gliss | Connection Type: POST PORT: 80 AUTH/HEADER: NONE |
Silent Gliss Command Generator |
| Somfy | Connection Type: POST PORT: 8443 Authentication = HEADER Header data = {"Authorization":"Bearer [TOKEN]"} |
Somfy Command Generator |
